1
2
3
4
1

Spray booth (includes FlyDry robot to dry paint + burner)

2

Working bay

3

Working bay

4

PaintRoom

MINiLine for express repairs

  • 8 to 10 BOOTH CYCLES per day

  • 1 or 2 panels

  • small and medium DAMAGES

  • 3 TECHNICIANS WORKING CONTINUOUSLY

Thanks to the CarMover, Symach MiniLine connects the 2 working bays on both sides of the spray booth to it, through 2 side pneumatic doors.

The MiniLine includes:

  • 1 spray booth (equipped with burner and FlyDry robot to dry the paint)
  • 2 working bays (one right and one left of the spraybooth)
  • 1 PaintRoom
  • CarMover side-loading system

MiniLine can host 3 technicians working continuously without any interruption, to produce 8 to 10 jobs per day (shift of 8 hours).

Characteristics of the spray booth:

    • Length 8 m. (26 ft.)
    • Width 4.5 m. (15 ft.)
    • Height 3 m. (10 ft.)
    • 2 side pneumatic doors 7 X h 2.2 m. (23 X h 7.2 ft.)
    • Main door in stainless steel 3 X h 2.85 m. (10 X h 9.3 ft.)
    • Burner 170 Kw
    • 2 Fans inverter 7.5 Kw 24000 m3/h
    • PLC + touch screen 15”
    • Frontal vertical extraction (no downdraft)
