It is a small infrared oven used to dry the disassembled parts of a car, such as bumpers, fenders, and doors
IMAGES
VIDEOS
It is a small infrared oven used to dry the disassembled parts of a car, such as bumpers, fenders, and doors.
It is an excellent solution to lighten the drying activity in the paint booth.
Drying is performed using Drytronic infrared technology, which ensures a drying time of less than 50% compared to traditional paint booths.
Additionally, the drying cost is less than 10% of that of a traditional paint booth.
IR DRYBOX 25
DRYBOX
Infrared drying cabin
| Drying technology | IR DRYBOX | CLASSIC SPRAY BOOTH |
| Primer | 0:15 minutes | 0:30 minutes |
| Waterborne drying time | 0:15 minutes | 0:30 minutes |
| Clear drying time | 0:15 minutes | 0:30 minutes |
MANAGEMENT AND CONTROL SYSTEM
| MiniPC | RASPBERRY |
| Touch screen | 7″ HD |
CONFIGURABLE WORK PROGRAMS
| Drying | Multiple program configurable |
PAINT BOOT MEASURE
| m. | ft. | |
|---|---|---|
| Internal length | 2,00 | 6,56 |
| External length | 2,20 | 7,22 |
| Internal width | 4,00 | 13,12 |
| External width | 4,20 | 13,78 |
| Internal height | 2,90 | 9,51 |
| External height | 3,30 | 10,83 |
VENTILATION GROUP ON THE ROOF
| Rear positioning | YES | YES |
| Side positioning | YES | YES |
| Intake motor | 0.37 Kw | 0.5 HP |
| Extraction motor | 0.37 Kw | 0.5 HP |
| Intake fan | 1.200 mc/h | 700 CFM |
| Exhaust fan | 1.200 mc/h | 700 CFM |
INFRARED CATHALYTIC
| Number of catalytic panels in line | 2 | |
| Lenght of the panel | m. 0.90 | ft. 2.95 |
| Panel widht | m. 0.50 | ft. 1.64 |
| Power generated | 34 Kw | 120.000 BTU |
| NATURAL GAS | 3.4 mc/h | 2.0 CFM |
| LPG | 1.7 kg/h | 3.7 lb/h |
MANUFACTURING
| mm | Gauge | |
|---|---|---|
| Stainless steel floor | 1.0 | 18 |
| Sandwich panels wall mm 50 pre-painted white external stainless steel internal | 1.2 | 16 |
| Stainless steel ceiling | 1.0 | 18 |
| Galvanized sheet metal ducts | 1.0 | 18 |
| Ventilation group galvanized sheet metal | 3.0 | 8 |
| Door | m. 2 X H 2 | ft. 6.6 X 6.6 |
